Germany: Galion Becomes First Lidar to Be Approved for Low Cost Offshore Power Curve Tests

The Fraunhofer Institute for Wind Energy and Energy System Technology (Fraunhofer IWES) has verified the accuracy of Galion Lidar’s groundbreaking “remote mast” functionality.  This is the first independent validation of this novel wind measurement methodology within the industry.

The leading research institute states that Galion Lidar, a remote wind measurement device developed by international renewable energy consultancy, SgurrEnergy, “may be recommended […] for a power performance assessment offshore with the Galion Lidar installed on the transition piece of the test turbine”.

Power performance assessment of offshore wind turbines is essential to ensure they are working correctly, however the use of conventional met mast technology to carry out these tests comes at a high cost.  The innovation of low cost, Lidar-based alternatives to measure wind speed has been stimulated by the need to reduce these costs.

These include Lidars installed on fixed or floating platforms, on the nacelle of the test turbine, or acquiring remote mast measurements from the transition piece (the walkway at the bottom of the tower).  Floating and nacelle mounted solutions are explicitly excluded by current IEC standards, which state “only ground based remote sensing devices are used (e.g. nacelle mountings are not included)”.  Only Lidars situated on the transition piece of the test turbine or on fixed platforms comply with this IEC requirement.

According to the Fraunhofer IWES study, Galion Lidar’s “remote mast” capability allows measurements “where a horizontal distance between the location of the measurement device and its measurements is necessary”. This allows IEC compliant measurements to be obtained at a fraction of the costs of the current standard method by a Galion installed on the transition piece of an offshore wind turbine. The measurements were compared to an IEC compliant met mast, and “the results of the verification test indicate a good agreement”. The comparison was undertaken in moderately complex terrain and so “it is expected that the uncertainties [for offshore power curve tests] are even smaller […] since the influences of the terrain would be less significant for an offshore site”. The distance and height over which the test was conducted met the requirements of an IEC compliant power curve test.

Ian Irvine, technical director at SgurrEnergy, said: “The remote mast approach offers the lowest cost for power performance assessments offshore, and has none of the drawbacks of the alternatives. It is not affected by tower sway or obstruction by the blades; wind conditions such as shear are easily measured across the entire rotor disc; and there is an established and accepted calibration method. The obstacles that prevent wind farm owners from checking their wind turbines are working properly have been removed, as Galion Lidar provides the means to undertake reliable, repeatable, rapid and inexpensive tests offshore and can be easily deployed from a service vessel. This method also allows multiple turbines at an offshore wind project to be easily tested in succession.”

The Galion’s capabilities offshore have recently been demonstrated by a series of high profile deployments in the North Sea, Baltic Sea and South China Sea. Galion Lidar is currently performing an offshore power performance assessment on the transition piece of a wind turbine in the Alpha Ventus offshore wind farm as part of a joint measurement campaign with AREVA Wind.

The approval of Galion Lidar capabilities by Fraunhofer IWES follows a series of independent verifications of the device.  Galion was given the seal of approval by wind energy experts, Deutsche WindGuard in March, was independently certified by Risø DTU in Denmark and is routinely tested at SgurrEnergy’s remote sensing test facility at Carrot Moor in Scotland.

[mappress]

Press release, June 10, 2013; Image: sgurrenergy
